SPRS645F – AUGUST 2010 – REVISED OCTOBER 2013
1.2
Applications
?
?
?
?
?
?
?
Wireless Audio Devices (Headsets, Microphones, Speakerphones)
Echo Cancellation Headphones
Portable Medical Devices
Voice Applications
Industrial Controls
Fingerprint Biometrics
Software Defined Radio
1.3
Description
The device is a member of TI's TMS320C5000? fixed-point Digital Signal Processor (DSP) product family
and is designed for low-power applications.
The fixed-point DSP is based on the TMS320C55x? DSP generation CPU processor core. The C55x?
DSP architecture achieves high performance and low power through increased parallelism and total focus
on power savings. The CPU supports an internal bus structure that is composed of one program bus, one
32-bit data read bus and two 16-bit data read buses, two 16-bit data write buses, and additional buses
dedicated to peripheral and DMA activity. These buses provide the ability to perform up to four 16-bit data
reads and two 16-bit data writes in a single cycle. The device also includes four DMA controllers, each
with 4 channels, providing data movement for 16-independent channel contexts without CPU intervention.
Each DMA controller can perform one 32-bit data transfer per cycle, in parallel and independent of the
CPU activity.
The C55x CPU provides two multiply-accumulate (MAC) units, each capable of 17-bit x 17-bit
multiplication and a 32-bit add in a single cycle. A central 40-bit arithmetic/logic unit (ALU) is supported by
an additional 16-bit ALU. Use of the ALUs is under instruction set control, providing the ability to optimize
parallel activity and power consumption. These resources are managed in the Address Unit (AU) and Data
Unit (DU) of the C55x CPU.
The C55x CPU supports a variable byte width instruction set for improved code density. The Instruction
Unit (IU) performs 32-bit program fetches from internal or external memory and queues instructions for the
Program Unit (PU). The Program Unit decodes the instructions, directs tasks to the Address Unit (AU) and
Data Unit (DU) resources, and manages the fully protected pipeline. Predictive branching capability avoids
pipeline flushes on execution of conditional instructions.
The general-purpose input and output functions along with the 10-bit SAR ADC provide sufficient pins for
status, interrupts, and bit I/O for LCD displays, keyboards, and media interfaces. Serial media is supported
through two MultiMedia Card/Secure Digital (MMC/SD) peripherals, four Inter-IC Sound (I2S Bus?)
modules, one Serial-Port Interface (SPI) with up to 4 chip selects, one I2C multi-master and slave
interface, and a Universal Asynchronous Receiver/Transmitter (UART) interface.
The device peripheral set includes an external memory interface (EMIF) that provides glueless access to
asynchronous memories like EPROM, NOR, NAND, and SRAM, as well as to high-speed, high-density
memories such as synchronous DRAM (SDRAM) and mobile SDRAM (mSDRAM). Additional peripherals
include: a high-speed Universal Serial Bus (USB2.0) device mode only, and a real-time clock (RTC). This
device also includes three general-purpose timers with one configurable as a watchdog timer, and an
analog phase-locked loop (APLL) clock generator.
In addition, the device includes a tightly-coupled FFT Hardware Accelerator. The tightly-coupled FFT
Hardware Accelerator supports 8 to 1024-point (in power of 2) real and complex-valued FFTs.
2
Fixed-Point Digital Signal Processor
Product Folder Links: TMS320C5515
Copyright ? 2010–2013, Texas Instruments Incorporated
